Top Valve 2D and 3D Drawings

Top Valve Technical Drawings and 3D CAD Models

Please use our tabs below to first select which type of valve you are seeking drawings for, and then you can locate the specific model number.

All 2D models are in .dwg format, and all 3D models are in .stp format.

To download our .stp files, please right-click and select "Save Link As..." or "Save Target As...". If you are using Internet Explorer, ensure that you change the file extension from .htm to .stp when saving the file.

For more details on our Top Valve file coding system, please click here.

Top Valve Back Pressure and Pressure Relief Valves in Plastic and Metal

Metallic Back Pressure Valves

Threaded

.pdf	.dwg	.stp
TVBP25-SS.pdf	TVBP25-SS.dwg	TVBP25-SS.stp
TVBP25-SS-G.pdf	TVBP25-SS-G.dwg	TVBP25-SS-G.stp
TVBP45-SS.pdf	TVBP45-SS.dwg	TVBP45-SS.stp
TVBP45-SS-G.pdf	TVBP45-SS-G.dwg	TVBP45-SS-G.stp
TVBP50-SS.pdf	TVBP50-SS.dwg	TVBP50-SS.stp
TVBP50-SS-G.pdf	TVBP50-SS-G.dwg	TVBP50-SS-G.stp
TVBP75-SS.pdf	TVBP75-SS.dwg	TVBP75-SS.stp
TVBP75-SS-G.pdf	TVBP75-SS-G.dwg	TVBP75-SS-G.stp
TVBP10-SS.pdf	TVBP10-SS.dwg	TVBP10-SS.stp
TVBP10-SS-G.pdf	TVBP10-SS-G.dwg	TVBP10-SS-G.stp
TVBP15-SS.pdf	TVBP15-SS.dwg	TVBP15-SS.stp
TVBP15-SS-G.pdf	TVBP15-SS-G.dwg	TVBP15-SS-G.stp
TVBP20-SS.pdf	TVBP20-SS.dwg	TVBP20-SS.stp
TVBP20-SS-G.pdf	TVBP20-SS-G.dwg	TVBP20-SS-G.stp

Flanged

.pdf	.dwg	.stp
TVBFW45-SS.pdf	TVBFW45-SS.dwg	TVBFW45-SS.stp
TVBFW45-SS-G.pdf	TVBFW45-SS-G.dwg	TVBFW45-SS-G.stp
TVBFW50-SS.pdf	TVBFW50-SS.dwg	TVBFW50-SS.stp
TVBFW50-SS-G.pdf	TVBFW50-SS-G.dwg	TVBFW50-SS-G.stp
TVBFW75-SS.pdf	TVBFW75-SS.dwg	TVBFW75-SS.stp
TVBFW75-SS-G.pdf	TVBFW75-SS-G.dwg	TVBFW75-SS-G.stp
TVBFW10-SS.pdf	TVBFW10-SS.dwg	TVBFW10-SS.stp
TVBFW10-SS-G.pdf	TVBFW10-SS-G.dwg	TVBFW10-SS-G.stp
TVBFW15-SS.pdf	TVBFW15-SS.dwg	TVBFW15-SS.stp
TVBFW15-SS-G.pdf	TVBFW15-SS-G.dwg	TVBFW15-SS-G.stp
TVBFW20-SS.pdf	TVBFW20-SS.dwg	TVBFW20-SS.stp
TVBFW20-SS-G.pdf	TVBFW20-SS-G.dwg	TVBFW20-SS-G.stp

Plastic Back Pressure Valves

Threaded

.pdf	.dwg	.stp
TVBP25-PVC.pdf	TVBP25-PVC.dwg	TVBP25-PVC.stp
TVBP25-PVC-G.pdf	TVBP25-PVC-G.dwg	TVBP25-PVC-G.stp
TVBP45-PVC.pdf	TVBP45-PVC.dwg	TVBP45-PVC.stp
TVBP45-PVC-G.pdf	TVBP45-PVC-G.dwg	TVBP45-PVC-G.stp
TVBP50-PVC.pdf	TVBP50-PVC.dwg	TVBP50-PVC.stp
TVBP50-PVC-G.pdf	TVBP50-PVC-G.dwg	TVBP50-PVC-G.stp
TVBP75-PVC.pdf	TVBP75-PVC.dwg	TVBP75-PVC.stp
TVBP75-PVC-G.pdf	TVBP75-PVC-G.dwg	TVBP75-PVC-G.stp
TVBP10-PVC.pdf	TVBP10-PVC.dwg	TVBP10-PVC.stp
TVBP10-PVC-G.pdf	TVBP10-PVC-G.dwg	TVBP10-PVC-G.stp
TVBP15-PVC.pdf	TVBP15-PVC.dwg	TVBP15-PVC.stp
TVBP15-PVC-G.pdf	TVBP15-PVC-G.dwg	TVBP15-PVC-G.stp
TVBP20-PVC.pdf	TVBP20-PVC.dwg	TVBP20-PVC.stp
TVBP20-PVC-G.pdf	TVBP20-PVC-G.dwg	TVBP20-PVC-G.stp

Flanged PVC/CPVC

.pdf	.dwg	.stp
TVBF45-PVC.pdf	TVBF45-PVC.dwg	TVBF45-PVC.stp
TVBF45-PVC-G.pdf	TVBF45-PVC-G.dwg	TVBF45-PVC-G.stp
TVBF50-PVC.pdf	TVBF50-PVC.dwg	TVBF50-PVC.stp
TVBF50-PVC-G.pdf	TVBF50-PVC-G.dwg	TVBF50-PVC-G.stp
TVBF75-PVC.pdf	TVBF75-PVC.dwg	TVBF75-PVC.stp
TVBF75-PVC-G.pdf	TVBF75-PVC-G.dwg	TVBF75-PVC-G.stp
TVBF10-PVC.pdf	TVBF10-PVC.dwg	TVBF10-PVC.stp
TVBF10-PVC-G.pdf	TVBF10-PVC-G.dwg	TVBF10-PVC-G.stp
TVBF15-PVC.pdf	TVBF15-PVC.dwg	TVBF15-PVC.stp
TVBF15-PVC-G.pdf	TVBF15-PVC-G.dwg	TVBF15-PVC-G.stp
TVBF20-PVC.pdf	TVBF20-PVC.dwg	TVBF20-PVC.stp
TVBF20-PVC-G.pdf	TVBF20-PVC-G.dwg	TVBF20-PVC-G.stp

Flanged PVDF/PP

.pdf	.dwg	.stp
TVBF45-PP.pdf	TVBF45-PP.dwg	TVBF45-PP.stp
TVBF45-PP-G.pdf	TVBF45-PP-G.dwg	TVBF45-PP-G.stp
TVBF50-PP.pdf	TVBF50-PP.dwg	TVBF50-PP.stp
TVBF50-PP-G.pdf	TVBF50-PP-G.dwg	TVBF50-PP-G.stp
TVBF75-PP.pdf	TVBF75-PP.dwg	TVBF75-PP.stp
TVBF75-PP-G.pdf	TVBF75-PP-G.dwg	TVBF75-PP-G.stp
TVBF10-PP.pdf	TVBF10-PP.dwg	TVBF10-PP.stp
TVBF10-PP-G.pdf	TVBF10-PP-G.dwg	TVBF10-PP-G.stp
TVBF15-PP.pdf	TVBF15-PP.dwg	TVBF15-PP.stp
TVBF15-PP-G.pdf	TVBF15-PP-G.dwg	TVBF15-PP-G.stp
TVBF20-PP.pdf	TVBF20-PP.dwg	TVBF20-PP.stp
TVBF20-PP-G.pdf	TVBF20-PP-G.dwg	TVBF20-PP-G.stp

Metallic Pressure Relief Valves

Threaded

.pdf	.dwg	.stp
TVPR25-SS.pdf	TVPR25-SS.dwg	TVPR25-SS.stp
TVPR25-SS-G.pdf	TVPR25-SS-G.dwg	TVPR25-SS-G.stp
TVPR45-SS.pdf	TVPR45-SS.dwg	TVPR45-SS.stp
TVPR45-SS-G.pdf	TVPR45-SS-G.dwg	TVPR45-SS-G.stp
TVPR50-SS.pdf	TVPR50-SS.dwg	TVPR50-SS.stp
TVPR50-SS-G.pdf	TVPR50-SS-G.dwg	TVPR50-SS-G.stp
TVPR75-SS.pdf	TVPR75-SS.dwg	TVPR75-SS.stp
TVPR75-SS-G.pdf	TVPR75-SS-G.dwg	TVPR75-SS-G.stp
TVPR10-SS.pdf	TVPR10-SS.dwg	TVPR10-SS.stp
TVPR10-SS-G.pdf	TVPR10-SS-G.dwg	TVPR10-SS-G.stp
TVPR15-SS.pdf	TVPR15-SS.dwg	TVPR15-SS.stp
TVPR15-SS-G.pdf	TVPR15-SS-G.dwg	TVPR15-SS-G.stp
TVPR20-SS.pdf	TVPR20-SS.dwg	TVPR20-SS.stp
TVPR20-SS-G.pdf	TVPR20-SS-G.dwg	TVPR20-SS-G.stp

Flanged

.pdf	.dwg	.stp
TVPFW45-SS.pdf	TVPFW45-SS.dwg	TVPFW45-SS.stp
TVPFW45-SS-G.pdf	TVPFW45-SS-G.dwg	TVPFW45-SS-G.stp
TVPFW50-SS.pdf	TVPFW50-SS.dwg	TVPFW50-SS.stp
TVPFW50-SS-G.pdf	TVPFW50-SS-G.dwg	TVPFW50-SS-G.stp
TVPFW75-SS.pdf	TVPFW75-SS.dwg	TVPFW75-SS.stp
TVPFW75-SS-G.pdf	TVPFW75-SS-G.dwg	TVPFW75-SS-G.stp
TVPFW10-SS.pdf	TVPFW10-SS.dwg	TVPFW10-SS.stp
TVPFW10-SS-G.pdf	TVPFW10-SS-G.dwg	TVPFW10-SS-G.stp
TVPFW15-SS.pdf	TVPFW15-SS.dwg	TVPFW15-SS.stp
TVPFW15-SS-G.pdf	TVPFW15-SS-G.dwg	TVPFW15-SS-G.stp
TVPFW20-SS.pdf	TVPFW20-SS.dwg	TVPFW20-SS.stp
TVPFW20-SS-G.pdf	TVPFW20-SS-G.dwg	TVPFW20-SS-G.stp

Plastic Pressure Relief Valves

Threaded

.pdf	.dwg	.stp
TVPR25-PVC.pdf	TVPR25-PVC.dwg	TVPR25-PVC.stp
TVPR25-PVC-G.pdf	TVPR25-PVC-G.dwg	TVPR25-PVC-G.stp
TVPR45-PVC.pdf	TVPR45-PVC.dwg	TVPR45-PVC.stp
TVPR45-PVC-G.pdf	TVPR45-PVC-G.dwg	TVPR45-PVC-G.stp
TVPR50-PVC.pdf	TVPR50-PVC.dwg	TVPR50-PVC.stp
TVPR50-PVC-G.pdf	TVPR50-PVC-G.dwg	TVPR50-PVC-G.stp
TVPR75-PVC.pdf	TVPR75-PVC.dwg	TVPR75-PVC.stp
TVPR75-PVC-G.pdf	TVPR75-PVC-G.dwg	TVPR75-PVC-G.stp
TVPR10-PVC.pdf	TVPR10-PVC.dwg	TVPR10-PVC.stp
TVPR10-PVC-G.pdf	TVPR10-PVC-G.dwg	TVPR10-PVC-G.stp
TVPR15-PVC.pdf	TVPR15-PVC.dwg	TVPR15-PVC.stp
TVPR15-PVC-G.pdf	TVPR15-PVC-G.dwg	TVPR15-PVC-G.stp
TVPR20-PVC.pdf	TVPR20-PVC.dwg	TVPR20-PVC.stp
TVPR20-PVC-G.pdf	TVPR20-PVC-G.dwg	TVPR20-PVC-G.stp

Flanged PVC/CPVC

.pdf	.dwg	.stp
TVPF45-PVC.pdf	TVPF45-PVC.dwg	TVPF45-PVC.stp
TVPF45-PVC-G.pdf	TVPF45-PVC-G.dwg	TVPF45-PVC-G.stp
TVPF50-PVC.pdf	TVPF50-PVC.dwg	TVPF50-PVC.stp
TVPF50-PVC-G.pdf	TVPF50-PVC-G.dwg	TVPF50-PVC-G.stp
TVPF75-PVC.pdf	TVPF75-PVC.dwg	TVPF75-PVC.stp
TVPF75-PVC-G.pdf	TVPF75-PVC-G.dwg	TVPF75-PVC-G.stp
TVPF10-PVC.pdf	TVPF10-PVC.dwg	TVPF10-PVC.stp
TVPF10-PVC-G.pdf	TVPF10-PVC-G.dwg	TVPF10-PVC-G.stp
TVPF15-PVC.pdf	TVPF15-PVC.dwg	TVPF15-PVC.stp
TVPF15-PVC-G.pdf	TVPF15-PVC-G.dwg	TVPF15-PVC-G.stp
TVPF20-PVC.pdf	TVPF20-PVC.dwg	TVPF20-PVC.stp
TVPF20-PVC-G.pdf	TVPF20-PVC-G.dwg	TVPF20-PVC-G.stp

Flanged PP/PVDF

.pdf	.dwg	.stp
TVPF45-PP.pdf	TVPF45-PP.dwg	TVPF45-PP.stp
TVPF45-PP-G.pdf	TVPF45-PP-G.dwg	TVPF45-PP-G.stp
TVPF50-PP.pdf	TVPF50-PP.dwg	TVPF50-PP.stp
TVPF50-PP-G.pdf	TVPF50-PP-G.dwg	TVPF50-PP-G.stp
TVPF75-PP.pdf	TVPF75-PP.dwg	TVPF75-PP.stp
TVPF75-PP-G.pdf	TVPF75-PP-G.dwg	TVPF75-PP-G.stp
TVPF10-PP.pdf	TVPF10-PP.dwg	TVPF10-PP.stp
TVPF10-PP-G.pdf	TVPF10-PP-G.dwg	TVPF10-PP-G.stp
TVPF15-PP.pdf	TVPF15-PP.dwg	TVPF15-PP.stp
TVPF15-PP-G.pdf	TVPF15-PP-G.dwg	TVPF15-PP-G.stp
TVPF20-PP.pdf	TVPF20-PP.dwg	TVPF20-PP.stp
TVPF20-PP-G.pdf	TVPF20-PP-G.dwg	TVPF20-PP-G.stp

Dimensional Drawings

Top Valve Back Pressure Standard Drawing in PDF

Top Valve Pressure Relief Drawing in PDF

Flanged Dimensional Drawings

Back Pressure Style	Pressure Relief Style
TVBF Flanged PVC/CPVC.pdf	TVPF Flanged PVC/CPVC.pdf
TVBF Flanged PP/PVDF.pdf	TVPF Flanged PP/PVDF.pdf
TVBF Flanged Alloyed Threaded.pdf	TVPF Flanged Alloyed Threaded.pdf
TVBF Flanged Alloyed Welded.pdf	TVPF Flanged Alloyed Welded.pdf

Exploded Views

Standard Top Valve Exploded View

Top Valve High Pressure Exploded View

Top Valve High Temperature Exploded View
